MOVE SINGLE - Installation guide
Desk Clamp
Tighten
Tabletop
Adaptable tabletop thickness
20-25mm
Tabletop
Through Desk Mounting
Attaching Monitor
Cable Management
Tabletop
on actual situation
After using, please put
the 4X4 Allen key(E)
here for storage.
To adjust the swivel function use
5x5 allen key(F) on position 1
To adjust the tilt function use
5x5 allen key(F) on position 2
Choose use washer(D) based
Cable
Tabletop
After installation, In case of display rising or dropping
automatically, please use 4x4MM allen key (E) tighten the
screw in the direction of " " to increase the friction with
display stopping normally . If you feel hard in using after
stopping of display, tighten the screw in the direction of
" " to release the friction.
Desk clamp
Through desk mounting
Attaching monitor
