Movement C5 INDOOR CYCLE - Page 58

18
PARTS LIST
DESCRIPTION
1 - Hex. Cyl Head
Screw - M8X50
2x
QTD.
DESCRIPTION
2 - Pressure washer
4x
QTD.
DESCRIPTION
A - Rear Base
TOOLS
Allen Wrench °6
100%
EQUIPMENT ASSEMBLY
STEP 1
DESCRIPTION
3 - Flat washer
4x
QTD.
DESCRIPTION
C - Chassi
DESCRIPTION
B - Front base
1
2
3
1
2
3
DESCRIPTION
D1 - Left Pedal
DESCRIPTION
D2 - Right pedal
B
A
D2
D1
Fixed Wrench
C
