Movement EDGE - Assemble Rod Guides and Retention Rings

CAREFULL TO NOT
DAMAGE HE PLASTIC
BUSHING OF THE
TOP PLATE
Rods
NAME
STEP 11 - ASSEMBLE THE RODS
Retention ring
NAME QTY
4x
16
16
N
Figure 11-1
Figure 11-2
26
ASSEMBLE
Keep distance between
the hole and the adhesive
of 10 mm
N
49
49
Rod guide
NAME
QTY
2x
49
