Movement EDGE - Assemble Base Support Structure

ASSEMBLE
STEP 12 - ASSEMBLE THE SUPPORT
Internal hex head screw
M10X130
NAME QTY
2x
17
Flat washer
M10
NAME QTY
10x
2
Hex nut
M10
NAME QTY
2x
3
Fixation plate
NAME QTY
1x
18
Cam support
NAME
Plug
NAME QTY
6x
19
Hex head screw
M10X20
NAME QTY
6x
20
O
Fix Wrench 17 mm
Tools
27
Allen 8 mm
Toolss
Sticker thread lock
medium torque
19
20
2
2
3
17
2
18
17
2
18
2
3
Figura 12-1
O
B
