ASSEMBLE
STEP 13 - ASSEMBLE THE CAM AND THE LEG SUPPORT
28
Sticker thread lock
medium torque
Allen 6 mm
Tools
Cap
NAME
Internal Hex. Flat. Head Screw
M10X20
NAME Qty
1x
21
Cam
NAME
Arm
NAME
22
Figure 14-3
Qty
1x
Q
Q1
Backseat washer
NAME
30
Qty
1x
Figure 14-2
Internal Hex Head Screw
M12X90
NAME Qty
1x
51
Hex Nut Insert Nylon
M12
NAME Qty
1x
50
Leg support
NAME
Q2
Figure 14-1
Pulley cover
NAME
Qty
2x
9
Internal Hex. Flat. Head Screw
M8X20
NAME Qty
1x
53
Bush
NAME Qty
1x
57
leg Upholstered
NAME
Q3
52
Roller protector
NAME Qty
1x
52
Q3
9
53
43
Q2
51
50
Q1
58
Axis
NAME Qty
1x
58
21
22
30
