Movement IDEA - Page 55

5
12
2
Flat washer
M10
NAME Qty
8x
1
Screw Hex. Socket Cyl. Head
M10X80
NAME Qty
4x
STEP 1
A
Chassi
NAME
TOOLS
Allen n° 8
50%
ASSEMBLY
Screw threader
medium torque
B
Connection bar
NAME
B
A
2
2
2
2
1
5
5
5
Hex Nut Nylon
M10
NAME
Qtd
4x
