ASSEMBLY
CAREFUL!
Before starting to assemble the equipment, care must be taken in the following cases:
•Certifique que a embalagem não está danificada e que as partes e componentes do equipamento não estão avariadas.
•It is recommended that the equipment be unpacked at the place where it will be assembled.
•The assembly unit must be cleaned.
•The ground should be flat and level, firm / rigid to prevent treadmill instability.
•The space around the equipment must be free as described in this Manual (see Operational Instruction Chapter).
•It is recommended that the equipment be assembled away from moisture and away from sunlight in order to avoid damaging
the electronic parts of the equipment.
•The icons have a function to instruct the user in which the tool is to be used, how many people should make the assembling,
or cross-tighten the screws without determining the pitch.
Allen
Screw threader
medium torque
Wrench
Philips
TOOLS
TABLE OF SPECIFICATION OF
SCREW TIGHTENING TORQUE
ICONS
Fixed Wrench
50%
Don't fully tighten
the bolts.
100%
Fully tighten
the screws.
Assembly by two
people is
recommended.
Diameter [mm]
M6
Torque [N.m]
9-12
M8
22-29
M10
45-58
Pliers for
elastic rings
To Next Page
