PARTS LIST — 331, 332, 333, AND 344 MODELS
Item
No.
Description Mechanical Seal Models Packing Gland
Models
33101
33201
33301
34401
33104
33204
33304
34404
33108
33208
33308
34408 34411
1 Pump Body
330-1065-002 330-1910-002 340-1000-001
1A Discharge Housing
340-2362-000
1B Bearing Housing
330-4587-000
1C Pump Base
340-2369-000
2 Suction Housing
330-1064-002 330-1911-002 330-4536-000 330-1064-002
*21 Stator See Stator section
below.
*22 Rotor
See Rotor section below with circled
numbers for each series.
1
2 1 1
24 Joint
Carbon SteeI/NBR
320-1511-000
316 SS/NBR
320-3759-000
Carbon SteeI/NBR
320-1511-000
26 Drive Shaft
320-1499-000 320-2938-000 320-1499-000 320-2448-000
29
Bearing (2 req.) 630-0502-031
33 Bearing Spacer 320-1900-000
41 Packing Gland 320-0101-004
42 Packing 340-3396-005
47 Gland Bolt 619-1520-161
66 Snap Ring 320-1506-000
66A Snap Ring 320-4182000
69 Mechanical Seal 320-2424-000
77 Slinger Ring 320-6382-000 320-6384-000
100 Pipe Plug (3 req.) 610-0120-021
112 Screws (8 req.) 619-1430-103 320-5968-000 619-0860-081 619-1430-103
112C Screws (4 req.) 61 9-0890-281
135 Stator Ring (331 -332 only) 320-7812-000
215 Lock Washer (8 req.) 320-6464-000
*Recommended spare parts.
ModelsSTATORS
331 332 333 344
21
Standard Stator, NBR All Models 340-3501-120 340-3502-120 340-3503-120 340-3504-120
21
EPDM Stator 340-3501-320 340-3502-320 340-3503-320 340-3504-320
21
FPM Stator 340-3501-520 340-3502-520 340-3503-520 340-3504-520
ROTORS
22
1 416SS - All Models
320-2729-000 330-0906-000 320-1394-000 320-1841-000
22
2 316SS — All Models
320-2933-000 320-2942-000 320-2936-000 320-2934-000
See page 8 for Repair/Conversion Kits
