CHANGE THE DIRECTION OF DOOR OPENING
Make sure the device is disconnected and emptied.
To remove the door, tilt the unit backwards. It should rest against something stable so that it
does not slip when the door is moved.
All removed parts must be retained while re-mounting of the door.
Do not lay the device flat as this may damage the coolant system.
Assembly requires the presence of two persons.
1. Remove the upper right hinge cover.
2. Open the door. Remove the screws. Then remove the hinge holder.
Place the door on a surface that is protected from scratching.
3. Remove the upper left hinge cover. Move the main cover from the left
to the right side.
