8. Put on the device. Put the door back using the lower hinge. Make sure
that the lower hinge core is well inserted into the door opening. Screw
the upper hinge on. Make sure that the door is aligned horizontally and
vertically so that the seals adhere to all edges. Put on the hinge cover
and screw it again.
9. Remove the door seal and put it back after rotating it.
MOUNTING
SURFACE REQUIREMENTS
Choose a location without direct sunlight.
Choose a location with an even (or almost levelled) floor.
Provide enough space to mount the refrigerator on a flat surface.
During mounting, leave space to the right and left, back and top. This will help reduce energy
consumption and lower electricity bills.
Provide enough space for opening the door.
Ensure a clearance of at least 50 mm on both sides.
A
B
C
D min= 0
E min=50
F
G
H
600
600
1700
1200
F
F
F
