INSTRUCTIONS FOR USE
FUNCTIONAL PARTS
1.
RESET button
6.
1” male threaded connection
outlet (By request, 1” female
revolving nut)
2.
Dry stop indicator
7.
Line connection
3.
Voltage indicator
8.
1” male threaded connection
inlet (By request, 1” female
revolving nut)
4.
Motor connection
9.
Pressure gauge (Brio2000-M
and 2000-MT versions only)
5.
Operating pressure setting
screw
