OPERATION AND PARTS MANUAL

THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

To ﬁnd the latest revision of this

publication, visit our website at:

www.multiquip.com

Revision #0 (03/08/18)

SERIES

MODEL MVH128GH

REVERSIBLE PLATE COMPACTOR

(HONDA GX160UT2SCM GASOLINE ENGINE)

Table of Contents

Questions and Answers

S
Sonya BeardAug 3, 2025
Why is the MQ Multiquip MVH128GH travel speed low and vibration weak?
- M
  Mr. Anthony SingletonAug 3, 2025
  Low travel speed and weak vibration in your MQ Multiquip Other can be caused by several factors. First, check if the clutch or V-belt are slipping; adjust or replace them if necessary. Also, verify the oil level in the vibrator and correct it if it's excessive. Issues within the vibrator assembly, such as worn or defective parts, can also cause this problem, so inspect and replace any faulty components. Additionally, ensure there's no air in the hydraulic oil for the travel reversing system by purging it. Finally, confirm that the engine speed is set to the correct RPM.
M
melodyramirezAug 10, 2025
What to do if MQ Multiquip Other travels forward or backward but cannot switch direction?
- N
  Nicholas GreenAug 10, 2025
  If your MQ Multiquip Other travels forward or backward but won't switch direction, consider these potential causes: First, inspect the hydraulic pump for any issues. Ensure the Direction Control Lever is correctly installed. Replace any broken or defective oil hoses. Purge any air from the hydraulic oil using the bleed plug. Correct the oil level if there's excessive oil in the reversing system. Clean the valve inside the hydraulic pump if it's clogged. Finally, check the cylinder piston bearing for leakage.
N
Nathan ColeAug 18, 2025
How to troubleshoot MQ Multiquip MVH128GH Other that does not travel in forward or reverse?
- J
  Janice MyersAug 19, 2025
  If your MQ Multiquip Other isn't moving in either direction, check the following: * Ensure the V-belt is engaged and not slipping; adjust or replace it if needed. * Adjust the clutch or replace it if it's slipping. * Inspect the vibrator for any locks and correct the problem. * Check the cylinder piston bearing for leakage at the USH packing.
H
heather72Aug 27, 2025
Why is the Direction Control Lever operating resistance high for reverse on my MQ Multiquip MVH128GH Other?
- A
  April HigginsAug 27, 2025
  High operating resistance for reverse on the Direction Control Lever of your MQ Multiquip Other may be due to the following reasons: * The piston inside the hydraulic pump may not be moving smoothly; adjust or replace it. * The vibrator cylinder piston may not be moving smoothly; adjust or replace it.
