DIAGRAM OF PARTS
Water reservoir Lid
PoWer indicator
Light (red)
BreW Button
With indicator
Light (green)
steam Button With
indicator Light (green)
ready indicator
Light (green)
removaBLe
driP tray
and driP
grid
measuring scooP
BreW steam PoWer ready
Frothing
tuBe caP
Frothing tuBe
BreW
Basket/
FiLter
hoLder
FiLters
(For 1 & 2 demitasses)
removaBLe Large/cLear
Water reservoir
FiLter
retention
cLiP
BreW
head
controL
knoB
on/oFF
Button
NOTE: Demitasse cups pictured are
not included.
Frothing tuBe tiP
Frothing tuBe vaLve
