Page 6mrcool.com
Appliance Overview
1
1
1
(this)
1
Owner’s Manual
Drain Plug
Drainage Connector
OPTIONAL
No-Vac
®
Quick Connect
®
Lineset
Gas / Liquid
Pipe Assembly
PART LOOKS LIKE... QUANTITY
Unless otherwise stated (as “OPTIONAL”) the air conditioning system includes the following
accessories. Use all of the installation parts and accessories to install the air conditioner.
Improper installation may result in water leakage, electrical shock, fire, or equipment failure.
Fig. 1.1
Please read this manual carefully before installation and keep it for future reference.
Copyright © 2019 MRCOOL, LLC
Thank you for choosing MRCOOL Please read this manual carefully before installation and keep it for future reference.
Owner’s Manual
Universal™ Series
Central Heating & Air Conditioning
