507769C05 Page 3 of 55
mrcool.com
Figure 1.
CONTROL BOX
(Includes integrated control,
transformer and door switch)
BAG ASSEMBLY
BLOWER MOTOR
(hidden)
COMBUSTION
AIR INDUCER
BURNER BOX ASSEMBLY
(includes flame sensor, rollout switches and ignitor)
GAS VALVE
BLOWER DECK
HEAT EXCHANGER
COLD END HEADER BOX
PRIMARY LIMIT
BLOWER
ACCESS PANEL
HEATING
ACCESS PANEL
COMPARTMENT
COMPARTMENT
Parts Arrangement
