507769C05 Page 47 of 55
MGD96SE090C4XA Performance (Less Filter)
External
Static
Pressure
in. w.c.
Air Volume / Watts at Dierent Blower Speeds
High Medium-High Medium Medium-Low Low
cfm watts cfm watts cfm watts cfm watts cfm watts
0.00 1760 435 1555 280 1405 230 1315 175 1190 135
0.10 1730 445 1515 300 1375 240 1280 190 1150 145
0.20 1700 455 1475 315 1350 250 1245 205 1115 155
0.30 1670 465 1445 330 1310 265 1200 220 1070 165
0.40 1640 480 1410 340 1265 275 1160 230 1025 175
0.50 1590 485 1380 345 1225 285 1125 235 985 185
0.60 1530 465 1340 360 1195 295 1085 245 945 195
0.70 1445 450 1315 370 1150 305 1065 255 895 200
0.80 1350 420 1280 375 1115 315 1015 265 860 210
MGD96SE110C5XA Performance (Less Filter)
External
Static
Pressure
in. w.c.
Air Volume / Watts at Dierent Blower Speeds
High Medium-High Medium Medium-Low Low
cfm watts cfm watts cfm watts cfm watts cfm watts
0.00 2115 669 1895 466 1710 356 1605 285 1415 209
0.10 2090 686 1845 476 1670 368 1570 299 1380 217
0.20 2060 701 1790 487 1630 375 1520 315 1320 222
0.30 2020 711 1760 498 1590 393 1470 324 1280 236
0.40 1980 734 1715 511 1545 403 1420 342 1220 247
0.50 1935 740 1690 525 1500 418 1370 347 1170 264
0.60 1895 749 1625 536 1460 423 1335 358 1110 269
0.70 1830 738 1600 548 1410 438 1280 367 1080 286
0.80 1765 723 1550 564 1370 456 1240 387 1010 290
NOTE: All air data is measured external to unit without lter (not furnished - eld provided)
Allowable Heating Speeds
Model Red Yellow Blue Brown Black
045 Allowed Factory Setting Allowed Not Allowed Not Allowed
070 Allowed Factory Setting Allowed Not Allowed Not Allowed
090 Allowed Factory Setting Allowed Allowed Not Allowed
010 Allowed Allowed Allowed Factory Setting Not Allowed
Table 21.
Allowable Circulation Speeds
Model Red Yellow Blue Brown Black
All Models Factory Setting Not Allowed Not Allowed Not Allowed Not Allowed
Table 22.
