Page 3
16 SEER SPLIT SYSTEM AIR CONDITIONER
ACCESSORIES
Description Where Used Kit Number
Low Ambient Kit All Models MLACK
Loss Of Charge Kit All Models (Factory Installed)
TXV Kit
18, 24, 30 H4TXV01
36, 42, 48 H4TXV02
60 H4TXV03
MAC16*A
REFRIGERATION DATA
Model
Refrig. Charge
(oz.) *
TXV
Refrigerant Line Size
Outdoor Unit
Connection
Indoor Unit Connection
Suction Liquid Suction Liquid Suction Liquid
MAC16018A
73 H4TXV01 3/4 3/8 3/4 3/8 3/4 3/8
MAC16024A 73 H4TXV01 3/4 3/8 3/4 3/8 3/4 3/8
MAC16030A
88 H4TXV01 3/4 3/8 3/4 3/8 3/4 3/8
MAC16036A
113 H4TXV02 7/8 3/8 7/8 3/8 7/8 3/8
MAC16042A 140 H4TXV02 7/8 3/8 7/8 3/8 7/8 3/8
MAC16048A 156 H4TXV02 7/8 3/8 7/8 3/8 7/8 3/8
MAC16060A 192 H4TXV03 1 1/8 3/8 7/8 ** 3/8 7/8 3/8
*Factory charged for 15 feet of line set
** Adapter shipped with unit
NOTE:
For the latest AHRI system matches please visit
https://www.ahridirectory.org
www.mrcool.com
All specifications and illustrations subject to change
without notice and without incurring obligations.
