MrCool Signature Series Installation Manual

Save these instructions for future reference
INSTALLATION INSTRUCTIONS
Signature Series Modular Blower
Manufactured By:
MRCOOL
®
, LLC
48 Remington Way
Hickory, KY 42051
This manual must be left with the homeowner for future reference.
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in
manuals, be alert to the potential for personal injury or death.
Table of Contents
Installation ...................................................................2
Condensate Drain Connection ....................................4
Electrical Wiring ...........................................................5
Setup ...........................................................................6
Sequence of Operation................................................8
System Check .............................................................9
Replacement Parts ....................................................10
Maintenance ..............................................................10
................................................11
Improper installation, adjustment, service, or
maintenance can cause injury or property damage.
Refer to this manual. For assistance or additional
agency.
WARNING
The information contained in this manual is intended
safety procedures and equipped with the proper tools
and test instruments. Failure to carefully read and follow
all instructions in this manual can result in equipment
malfunction, property damage, personal injury, and/or
death.
WARNING
Disconnect all power supplies to both the indoor
blower section and outdoor section before making any
electrical connections or servicing the system. More
than one disconnect switch may be required to de-
energize the equipment. Hazardous voltage can cause
severe personal injury or death.
WARNING
Inspection of Shipment
Upon receipt of equipment, carefully inspect it for possible
shipping damage. If damage is found, it should be noted
on the carrier’s freight bill. Take special care to examine
the unit inside the carton if the carton is damaged. Any
concealed damage discovered should be reported to the
last carrier immediately, preferably in writing, and should
include a request for inspection by the carrier’s agent.
If any damages are discovered and reported to the carrier
DO NOT INSTALL THE UNIT, as claim may be denied.
ordered.
Page 1
mrcool.com

MrCool Signature Series Specifications

General

Brand	MrCool
Model	Signature Series
Category	Furnace
Language	English
