MrCool Signature Series Installation Manual

Control Board Taps
Model Mode
Thermostat Cool Heat
HUM EM W1 O
Y2/
Y1
G A B C D A B C D
CFM CFM
MMBV08BE
Cont. Blower X 500 400 350 350
Cooling ** X X 1000 800 700 600
Heating X 1000 800 700 600
Aux. Heat X X *** *** *** *** 1000 800 700 600
Emer. Heat X X *** *** *** *** 1000 800 700 600
MMBV12BE
Cont. Blower X 600 500 400 350
Cooling ** X X 1200 1000 800 600
Heating X 1200 1000 800 600
Aux. Heat X X *** *** *** *** 1200 1100* 1100* 1100*
Emer. Heat X X *** *** *** *** 1200 1100* 1100* 1100*
MMBV16CE
Cont. Blower X 800 700 600 500
Cooling ** X X 1600 1400 1200 1000
Heating X 1600 1400 1200 1000
Aux. Heat X X *** *** *** *** 1600 1400 1200* 1100*
Emer. Heat X X *** *** *** *** 1600 1400 1200* 1100*
MMBV20DE
Cont. Blower X 900 800 700 600
Cooling ** X X 1800 1600 1400 1200
Heating X 1800 1600 1400 1200
Aux. Heat X X *** *** *** *** 1800 1600 1400 1200*
Emer. Heat X X *** *** *** *** 1800 1600 1400 1200*
* This CFM is not approved for use with highest kW heater size.
.
At the end of a call for cooling there is a blower delay of 1 minute.
Table 2. Variable Speed Motor Application
