MSA ZGARD S - Page 4

Table of Contents
Section 1 General Information and Applications 1.0
Section 2 Installation Guidelines
2.0
Section 3 ZGARD S Sensors, Operating Specifications and Features
3.0
Installation and Set-up RS485 Sensor Address Binary Coded Setup, Output Test, Cut-Off Feature
3.1
Section 4 ZGARD S Carbon Monoxide Solid-State (SS) Sensor, 4-20mA Output, Sensor Calibration
4.0
RS485 Output, Solid-State (SS) Sensor Calibration
4.1
Section 5 ZGARD S & DS Carbon Monoxide Electrochemical (EC) Sensor, 4-20mA Output, Sensor Calibration
5.0
RS485 Output, Electrochemical (EC) Sensor Calibration
5.1
Section 6 ZGARD S & DS Nitrogen Dioxide Electrochemical (EC) Sensor, 4-20mA Output, Sensor Calibration
6.0
RS485 Output, Electrochemical (EC) Sensor Calibration
6.1
Section 7 ZGARD S Refrigerant Solid-State (SS) Sensor, 4-20mA Output, Sensor Calibration
7.0
RS485 Output, Solid-State (SS) Sensor Calibration
7.1
Section 8 ZGARD S Ammonia Solid-State (SS) Sensor, 4-20mA Output, Sensor Calibration 8.0
RS485 Output, Solid-State (SS) Sensor Calibration
8.1
Section 9 ZGARD S & DS Sensors Start-Up Procedure
9.0
Section 10 Parts List
10.0
Drawings
106890B CO (SS), 4-20mA Output Sensor Circuit Board Layout
106891B CO (SS), RS485 Output Sensor Circuit Board Layout
106892B CO/NO2 (EC), 4-20mA Output Sensor Circuit Board Layout
106893B CO/NO2 (EC), RS485 Output Sensor Circuit Board Layout
106949B Rx (SS), 4-20mA Output Sensor Circuit Board Layout
106950B Rx (SS), RS485 Output Sensor Circuit Board Layout
106951B Ammonia (SS), 4-20mA Output Sensor Circuit Board Layout
106952B Ammonia (SS), RS485 Output Sensor Circuit Board Layout
106894B (SS) Sensors Calibration Gas (Humidified) Setup Procedure
106895B ZGARD S, Installation Outline, 4-20mA Output Sensor
106896B ZGARD S, Installation Outline, RS485 Digital Sensor
106897B ZGARD S, Installation Outline, 4-20mA Output, Stand-Alone Sensor
106953B ZGARD DS, Installation Outline, 4-20mA Output Sensors
106954B ZGARD DS, Installation Outline, RS485 Output Sensors
106955B ZGARD DS, Installation Outline, 4-20mA Output, Stand-Alone Sensors
