INSTALLATION INSTRUCTIONS
19
AUTOTRONIC CONTROLS CORPORATION • 1490 HENRY BRENNAN DR., EL PASO, TEXAS 79936 • (915) 857-5200 • FAX (915) 857-3344
FORD IGNITIONS Wiring a Ford TFI with Harness, PN 8874.
NOTE: Installation of a Timing Control with the Harness, see page 15.
CHRYSLER IGNITIONS Wiring a Chrysler Electronic Ignition using Magnetic Pickup Trigger.
