MSH Protos 380 - Page 55

Instructions Manual
Instructions Manual
55
where I can nd the parts
Box + Bag4 + Bag 12
Tail control assembly
ART. MSH41178
Tail blade Black
ART. MSH41181
Hex screw M2x16
ART. MSH41125
M2 Nut
ART. MSH41119
1
10mm
Remove coating with sandpaper
2
Apply a lm of slow
curing epoxy
3
Wait completely curing and
Mount it on the model
4
39 mm
Uniball Link L
ART. MSH41030
Only for micro servo
Cut 5 mm of tail control rod
