1 Coaxal S/PDIF-out port
1 Optcal S/PDIF-out port
5 USB 2.0 ports
2 USB 3.0 ports
1 ESATA/ USB 2.0 Combo port
2 LAN ports
6 󰘱exble audo ports
On-Board
3 USB 2.0 connectors
2 IEEE 1394 connectors
1 Seral port connector
1 Chasss Intruson connector
1 S/PDIF-out connector
1 Front Panel Audo connector
1 TPM Module connector
1 Power button
1 Reset button
1 OC Dal button
1 OC Dal knob
1 GreenPower button
1 Debug LED panel
Slots
5 PCI Express 2.0 x16 slots
PCI_E1 supports up to PCIE x16 speed (when PCI_E3 s empty)
PCI_E5 supports up to PCIE x16 speed (when PCI_E6 s empty)
f you ntend to nstall two expanson cards, please nstall them nto PCI_E1 &
PCI_E5 slots
PCI_E3 & PCI_E6 support up to PCIE x8 speed
f you ntend to nstall four expanson cards nto both PCI_E1, E3, E5 & E6 slots,
these four PCIE x16 lanes wll auto arrange from x16/ x0/ x16/ x0 to x8/ x8/ x8/ x8
PCI_E4 supports up to PCIE x4 speed
1 PCI Express 2.0 x1 slot
1 PCI slot, supports 3.3V/ 5V PCI bus Interface
Form Factor
ATX (24.5cm X 30.5 cm)
Mountng
9 mountng holes
Features on Focus
USB 3.0
SATA 6Gb/s
DrMOS nsde
Half H-C Cap desgn
Actve Phase Swtch feature to save power dynamcally
OC Gene Lte
OC Dal
Easy Button 2
USB Safeguard
M-Flash ncluded
CrossFreX
TM
-
-
-
-
-
-
-
■
-
-
-
-
-
-
-
-
-
-
-
-
-
■
-
-
-
-
-
-
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
