Hardware Setup
MS-7640
Chapter 2
2-11
Hardware Setup
MS-7640
Chapter 2
Connectors
IDE Connector: IDE1
Ths connector supports IDE hard dsk drves, optcal dsk drves and other IDE de-
vces.
* The MB layout n ths 󰘰gure s for reference only.
Important
If you nstall two IDE devces on the same cable, you must con󰘰gure the drves sepa-
rately to master / slave mode by settng jumpers. Refer to IDE devce’s documentaton
suppled by the vendors for jumper settng nstructons.
