Important
Manboard photos shown n ths secton are for demonstraton only. The appearance
of your manboard may vary dependng on the model you purchase.
Whle dsconnectng the Safety Hook from the 󰘰xed bolt, t s necessary to keep an
eye on your 󰘰ngers, because once the Safety Hook s dsconnected from the 󰘰xed
bolt, the 󰘰xed lever wll sprng back nstantly.
•
•
Poston the coolng set onto the re
-
tenton mechansm.
Hook one end of the clp to hook
󰘰rst.
5. Then press down the other end of the
clp to fasten the coolng set on the
top of the retenton mechansm.
Locate the Fx Lever and lft up t.
6.
Fasten down the lever.7. Attach the CPU Fan cable to the CPU
fan connector on the manboard.
8.
