MSI A68HI ACSeries User Manual

LAN ■ Realtek
®
RTL8111G Gigabit LAN controller
WLAN &
Bluetooth
■ Wi-Fi/Bluetooth expansion module with Intel Dual Band
Wireless-AC 7260 chip*.
- Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz,
5GHz) up to 867 Mbps speed.
- Supports Intel Wireless Display (WiDi)
- Supports Bluetooth v4.0 (includes BLE** and Bluetooth
3.0+HS)
* Only A68HI AC has a Wi-Fi/ Bluetooth module pre-installed.
** BLE: Bluetooth Low Energy
Back Panel
Connectors
■ 1x PS/2 keyboard/ mouse combo port
■ 2x USB 2.0 ports
■ 2x USB 3.0 ports
■ 1x VGA port
■ 1x DVI-D port
■ 1x HDMI port
■ 1x LAN (RJ45) port
■ 3x audio jacks
Internal
Connectors
■ 1x 24-pin ATX main power connector
■ 1x 4-pin ATX 12V power connector
■ 4x SATA 6Gb/s connectors
■ 1x USB 2.0 connector (supports additional 2 USB 2.0 ports)
■ 1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
■ 1x 4-pin CPU fan connector
■ 1x 4-pin system fan connector
■ 1x Front panel audio connector
■ 2x Front panel connectors
■ 1x Chassis Intrusion connector
■ 1x TPM module connector
■ 1x Clear CMOS jumper
BIOS
Features
■ 64 Mb 󰘱ash
■ UEFI AMI BIOS
■ ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
■ Multi-language
Form Factor ■ Mini-ITX Form Factor
■ 6.7 in. x 6.7 in. (17 cm x 17 cm)
