PCI_E1~2: PCIe Expansion Slots

The PCIe slot supports the PCIe interface expansion card.

PCIe x1 Slot

PCIe x16 Slot

PCI1: PCI Expansion Slot

The PCI slot supports the PCI interface expansion card..

PCI Slot

Important

󰘯

unplug the power supply power cable from the power outlet. Read the expansion

card’s documentation to check for any necessary additional hardware or software

changes.

Questions and Answers:

Need help?

Do you have a question about the MSI A68HM-E33 Series and is the answer not in the manual?

MSI A68HM-E33 Series Specifications

General

Form Factor	Micro ATX
Chipset	AMD A68H
Socket	FM2+
Memory Slots	2 x DIMM
Max Memory	32GB
PCI Slots	1
SATA Ports	4 x SATA 6Gb/s
USB 3.0 Ports	2
Memory Standard	DDR3
Audio	Realtek ALC887
LAN	Realtek RTL8111G
Video Outputs	VGA
USB 2.0 Ports	8 x USB 2.0 (4 rear, 4 via internal headers)
