Hardware Setup
Connectors
Seral ATA Connector: SATA1~6
Ths connector s a hgh-speed Seral ATA nterface port. Each connector can connect
to one Seral ATA devce.
* The MB layout n ths gure s for reference only.
SATA2
SATA3/
SATA4
SATA1
SATA5/
SATA6
Important
Please do not fold the Seral ATA cable nto 90-degree angle. Otherwse, data loss may
occur durng transmsson.
