Advanced DRAM Con󰘰guraton

Press <Enter> to enter the sub-menu.

Command Rate

Ths settng controls the DRAM command rate.

tCL

Ths controls the CAS latency, whch determnes the tmng delay (n clock cycles)

before SDRAM starts a read command after recevng t.

tRCD

When DRAM s refreshed, both rows and columns are addressed separately. Ths

setup tem allows you to determne the tmng of the transton from RAS (row address

strobe) to CAS (column address strobe). The less the clock cycles, the faster the

DRAM performance.

tRP

Ths settng controls the number of cycles for Row Address Strobe (RAS) to be

allowed to precharge. If nsu󰘲cent tme s allowed for the RAS to accumulate ts

charge before DRAM refresh, refreshng may be ncomplete and DRAM may fal

to retan data. Ths tem apples only when synchronous DRAM s nstalled n the

system.

tRAS

Ths settng determnes the tme RAS takes to read from and wrte to memory cell.

tRC

The row cycle tme determnes the mnmum number of clock cycles a memory row

takes to complete a full cycle, from row actvaton up to the prechargng of the actve

row.

tWR

Mnmum tme nterval between end of wrte data burst and the start of a precharge

command. Allows sense ampl󰘰ers to restore data to cells.

tRRD

Spec󰘰es the actve-to-actve delay of d󰘯erent banks.

▶
