Introductions
2-8 2-9
Left Side View
1. Kensington Lock
This notebook provides a Kensington lock hole, which allows users to secure the
notebook in place.
2. HDMI Connector
HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
3. USB 3.2 Gen 1
USB 3.2 Gen 1, the SuperSpeed USB, delivers the higher interface speeds for
connecting various devices, such as storage devices, hard drives, or video cameras,
and offers more advantages over high-speed data transferring.
4. Audio Port Connectors
Make high quality sound blaster with stereo system.
Microphone
• Used for an external microphone.
• Connect the Center and woofer speakers here.
Headphone out
• A connector for speakers or headphones.
• Connect the Front speakers here.
