Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1, SYS_FAN1~3 Fan Connectors 32
CPU_PWR1, ATX_PWR1 Power Connectors 30
CPU Socket LGA1151 CPU Socket 25
DIMMA1, DIMMA2,
DIMMB1, DIMMB2
DIMM Slots 26
JAUD1 Front Audio Connector 30
JBAT1 Clear CMOS (Reset BIOS) Jumper 35
JCI1 Chassis Intrusion Connector 33
JFP1, JFP2 Front Panel Connectors 28
JRGB1 RGB LED Connector 34
JTBT1 Thunderbolt Add-on Card Connector 34
JTPM1 TPM Module Connector 33
JUSB1 USB 2.0 Connector 31
JUSB2 USB 3.1 Gen1 Connector 31
M2_1 M.2 Slot (Key M) 29
PCI_E1~4 PCIe Expansion Slots 27
SATA1~4 SATA 6Gb/s Connectors 28
