MSI B360M PRO-VH User Manual

11
I/O I/O
M2_1: M.2 (Key M)
󱘕 󲓔M.2   (SSD)M.2    󱾫  󱝑   
ATX_PWR1CPU_PWR1: 󴻢
ATX󹧖󴻢󳰙󶪓
24
131
12
ATX_PWR1
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 Ground 15 Ground
4 +5V 16 PS-ON#
5 Ground 17 Ground
6 +5V 18 Ground
7 Ground 19 Ground
8 PWR OK 20 Res
9 5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 Ground
5
4
1
8
CPU_PWR1
1 Ground 5 +12V
2 Ground 6 +12V
3 Ground 7 +12V
4 Ground 8 +12V
󴱄󳞱
󲶿󲷢󱷼󱠓󶃘󲷭󾇄󹧗󴻣󸺁󱲸ATX󹧗󴻣
󳰛󶪔󶃘󸑃󱘕
1
2
3
4
5
󴱄󳞱
y Intel
®
RST UEFI ROM󱝑PCIe M.2 SSD  
y Intel
®
Optane™ 
30

MSI B360M PRO-VH Specifications

General

Form Factor	Micro-ATX
Chipset	Intel B360
Socket	LGA 1151
Memory Slots	2 x DIMM
Maximum Memory	32 GB
PCIe x16 Slots	1
M.2 Slots	1
Audio	Realtek ALC887
LAN	Realtek 8111H Gigabit LAN
RAID Support	No
Memory Speed	DDR4-2666/2400/2133 MHz
SATA Ports	4 x SATA 6Gb/s
USB 2.0 Ports	4
PCIe x1 Slots	2
