MSI CR610 - Left Side View

2-15
Introductions
Left Side View
1. RJ-45 Connector
The 10/100/1000 Ethernet connector is used to connect a LAN cable for network connection.
2. Audio Port Connectors
Make high quality sound blaster with stereo system and Hi-Fi function supported.
Headphone: A connector for speakers or
headphones.
Microphone: Used for an external microphone.
1. RJ-45 Connector
2. Audio Port Connectors
3. Ventilator
4. Card Reader
5. Express Card Slot
1
3
2
4 5
