Introductions
2-10
Left Side View
1. Kensington Lock
This notebook provides a Kensington Lock hole, which allows users to secure the notebook
in place with a key or some mechanical PIN device and attached through a rubberised metal
cable. The end of the cable has a small loop which allows the whole cable to be looped
around a permanent object, such as a heavy table or other similar equipment, thus securing
the notebook in place.
2. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator
3. Audio Port Connectors
Make high quality sound blaster with stereo system and Hi-Fi function supported.
Headphone
A connector for speakers or headphones.
Microphone
Used for an external microphone.
4. Power Connector
To connect the AC/DC adapter and supply power for the notebook.
