Introductions
Right Side View
1. Audio Port Connectors
Make high quality sound blaster with stereo system and Hi-Fi function supported. Connect your
speakers to the proper connectors as shown below.
Mic In: Used for an external microphone.
Connect the Center and Subwoofer speakers here.
Line In:
Used for an external audio device.
Connect the Rear Right and Left speakers
here.
Line Out/ S/PDIF-out : Used for speakers or
headphones.
2
1. Audio Port Connectors
2. USB Port
3. Card Reader
4. ExpressCard Slot
1
3
4
