2-19
Introductions
3. VGA Port
The 15-pin D-Sub VGA port allows you to connect an external monitor or other standard
VGA-compatible device (such as a projector) for a great view of the computer display.
4. USB Port
The USB 2.0 port allows you to connect USB-interface peripheral devices, such as the mouse,
keyboard, modem, portable hard disk module, printer and more.
5. RJ-45 Connector
The Ethernet connector is used to connect a LAN cable for network connection.
6. E-SATA (External Serial ATA) Port
The E-SATA Connector allows you to connect an external Serial ATA device. Users can now
utilize shielded cable outside the notebook to take advantage of the benefits the SATA interface
brings to storage.
7. Power Connector
To connect the AC/DC adapter and supply power for the notebook.
