MSI CX623 Disassemble Guide

CX623（MS-168A）Disassemble Guide
4、ODD MODULE
4.1：Remove the 1 screw (M2.5*5mm). Remove
the ODD Module according to the direction as pic
shows.
Attention: the screw driver torque: 1.5-2.0Kgf-cm
Component P/N Qty
Screw E43-1255001-G68 1
4.2：
Remove ODD Bezel as below.
Component P/N Qty
ODD Bezel E2P-681F211-Y31 1
4.3：
Remove 2pcs (M2*3mm) Screws Then remove
ODD Bracket as below.
Attention: the screw driver torque: 1.5-2.0Kgf-cm
Component P/N Qty
Screw E43-1203003-G68 2
ODD Bracket E2M-6813011-A89 1
ODD Module S7D-2270031-H44 1
