GT60（MS-16F3）Disassembly Guide
2、BOTTOM DOOR ASSY
2.1：Remove the 5 screws (M2.5*5mm).
Attention: the screw driver touque is: 2.5-3.0 gf-cm
Component P/N Qty
Screw E43-1205003-H29 2
2.2： Remove the 6 screws (M2.5*5mm). Then
remove the Bottom door.
Attention: the screw driver touque is: 2.5-3.0 gf-cm
Component P/N Qty
Bottom door 307-6F1J215-P89 1
Screw E43-1205003-H29 6
