GT60（MS-16F3）Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.1：Before remove K/B, firstly remove the Hinge
Cover. Care the Sensor board FPC below the
cover.
6.2：Remove the Sensor board.
Component P/N Qty
Sensor board
607-16F32-01S 1
Hinge Cover
307-6F3E211-Y31 1
6.3：Remove the LVDS and camera cable as pic
shows.
