GT60（MS-16F3）Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.4：Remove 1 screw (M2*3mm); then remove the
two side wireless card antenna as pic shows.
Attention: the screw driver torque is: 1.5-2.0Kgf-cm
Component P/N Qty
WLAN Module G51-N1WL069-X06 1
Screw E43-1203003-H29 1
6.5 ： Remove the 2 screws (M2.5*7mm) that
stabilize the left LCD hinge.
Attention: the screw driver torque is 3.0-3.5Kgf-cm
Component P/N Qty
Screw E43-1257002-G68 2
6.6 ： Remove the 2screws (M2.5*7mm) that
stabilize the right LCD hinge.
Attention: the screw driver torque is 3.0-3.5Kgf-cm
Component P/N Qty
Screw E43-1257002-G68 2
