MSI H87-G43 GAMING User Manual

Chapter 1
1-4Getting Started
Motherboard Speci󰘰cations
CPU
Support
4th Generation Intel
®
Core™ i7 / Core™ i5 / Core™ i3 / Pentium
®
/
Celeron
®
processors for LGA 1150 socket
■
Chipset Intel
®
Z87 Express Chipset (Z87-G43 GAMING)
Intel
®
H87 Express Chipset (H87-G43 GAMING)*
Intel
®
B85 Express Chipset (B85-G43 GAMING)*
* Supports Intel
®
SBA.
■
■
■
Memory
Support
4x DDR3 memory slots supporting up to 32GB
Supports DDR3 3000(OC)/ 2800(OC)/ 2666(OC)/ 2600(OC)/
2400(OC)/ 2200(OC)/ 2133(OC)/ 2000(OC)/ 1866(OC)/ 1600/ 1333/
1066 MHz
OC is for Z87-G43 GAMING only.
Dual channel memory architecture
Supports non-ECC, un-bu󰘯ered memory
Supports Intel
®
Extreme Memory Pro󰘰le (XMP)
■
■
-
■
■
■
Expansion
Slots
1x PCIe 3.0 x16 slot, supports up to PCIe 3.0 x16 speed
1x PCIe 2.0 x16 slot, supports up to PCIe 2.0 x4 speed
2x PCIe 2.0 x1 slots
3x PCI slots
■
■
■
■
Onboard
Graphics
1x VGA port, supports the maximum resolution of 1920x1200 @
60Hz
1x HDMI
®
port, supports the maximum resolutions of
4096x2160@24Hz, 24bpp/ 2560x1600@60Hz, 24bpp/
1920x1080@60Hz, 36bpp
1x DVI-D port, supports the maximum resolution of 1920x1200 @
60Hz
■
■
■
Multi-GPU
Support
Supports 2-Way AMD CrossFire
TM
Technology*
* Supports Windows 7 and Windows 8.
■
Storage Intel
®
Z87/ H87 Express Chipset
6x SATA 6Gb/s ports (SATA1~6)
Supports RAID 0, RAID1, RAID 5 and RAID 10
Supports Intel
®
Smart Response Technology, Intel
®
Rapid Start
Technology and Intel
®
Smart Connect Technology*
* Supports Intel
®
Core processors on Windows 7 and Windows 8.
■
-
-
-
Intel
®
B85 Express Chipset
4x SATA 6Gb/s ports (SATA1~4)
2x SATA 3Gb/s ports (SATA5~6)
Supports Intel
®
Rapid Start Technology and Intel
®
Smart Connect
Technology*
* Supports Intel
®
Core processors on Windows 7 and Windows 8.
■
-
-
-
Audio Realtek
®
ALC1150 Codec
7.1-Channel High De󰘰nition Audio
■
-

MSI H87-G43 GAMING Specifications

General

Brand	MSI
Model	H87-G43 GAMING
Category	Motherboard
Language	English
