MSI MAG 274QRFW User Manual

4
Installing the Monitor Stand
1. Leave the monitor in its protective foam packaging. Align the stand bracket to the
monitor groove.
2. Tighten the stand bracket with screws.
3. Connect the base to the stand and tighten the base screw to secure the base.
4. Make sure the stand assembly is properly installed before setting the monitor
upright.
1
2
3
⚠
Important
∙ Place the monitor on a soft, protected surface to avoid scratching the display panel.
∙ Do not use any sharp objects on the panel.
∙ The groove for installing the stand bracket can also be used for wall mount. Please
contact your dealer for proper wall mount kit.
∙ This product comes with NO protective film to be removed by the user! Any
mechanical damages to the product including removal of the polarizing film may
affect the warranty!

MSI MAG 274QRFW Specifications

General

Color depth	8 bit
Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Display diagonal	27 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 180 Hz
Maximum refresh rate	180 Hz
Horizontal scan range	64.56 - 266.4 kHz
Viewable size, vertical	335.664 mm
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Viewable size, horizontal	596.736 mm
Display brightness (typical)	400 cd/m²
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	DisplayHDR 400
DisplayPort version	1.4a
VGA (D-Sub) ports quantity	0
Input current	2.58 A
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
AC adapter output voltage	19 V
Power consumption (standby)	- W
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 20 °
Height adjustment	130 mm
Cable lock slot type	Kensington
Panel mounting interface	75 x 75 mm
Product color	White
Market positioning	Gaming
Package type	Box
Package depth	145 mm
Package width	847 mm
Package height	491 mm
Package weight	13300 g
Depth	197 mm
Width	614 mm
Height	402 mm
Weight	6050 g
