Specifications
Continued from previous page
Internal Connectors
∙ 1x 24-pin ATX main power connector
∙ 1x 8-pin ATX 12V power connector
∙ 4x SATA 6Gb/s connectors
∙ 2x M.2 slots (M-Key)
∙ 1x USB 3.2 Gen 1 5Gbps Type-C port
∙ 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2
USB 3.2 Gen 1 5Gbps ports)
∙ 2x USB 2.0 connectors (supports additional 4 USB 2.0
ports)
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin water-pump fan connector
∙ 3x 4-pin system fan connectors
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Serial port connector
∙ 1x Chassis Intrusion connector
∙ 2x 4-pin RGB LED connectors
∙ 2x 3-pin RAINBOW LED connectors
∙ 1xTPM module connector
∙ 1x Clear CMOS jumper
LED Features
∙ 1x EZ LED Control switch
∙ 4x EZ Debug LED
Back Panel
Connectors
∙ 1x Flash BIOS Button
∙ 1x Display port
∙ 1x HDMI port
∙ 4x USB 3.2 Gen 1 5Gbps Type-A ports
∙ 1x PS/2 keyboard/ mouse combo port
∙ 2x USB 2.0 Type-A ports
∙ 1x LAN (RJ45) port
∙ 3x Audio jacks
I/O Controller NUVOTON NCT6687-R Controller Chip
Continued on next page
