MSI MAG B560 TOMAHAWK WIFI User Guide

6
Specifications
Continued from previous column
Storage
 6x SATA 6Gb/s ports (from B560 chipset)
 3x M.2 slots (Key M)
 M2_1 slot (from CPU)
 Available only on 11th Gen Intel® CPU
 Supports up to PCIe 4.0 x4
 Supports 2242/ 2260/ 2280/ 22110 storage devices
 M2_2* slot (from B560 chipset)
 Supports up to PCIe 3.0 x4
 Supports SATA up to 6Gb/s
 Supports 2242/ 2260/ 2280 storage devices
 M2_3 slot (from B560 chipset)
 Supports up to PCIe 3.0 x4
 Supports 2242/ 2260/ 2280 storage devices
 Intel® Optane™ Memory Ready**
 Supports Intel® Smart Response Technology for Intel
Core™ processors
* SATA2 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
** Before using Intel® Optane™ memory modules, please ensure that you have
updated the drivers and BIOS to the latest version from MSI website.

 Intel® B560 Chipset
 
back panel)
 
through the internal connector)
 

connector)
 4x USB 2.0 ports on the back panel
 
 4x USB 2.0 ports available through the internal
connectors
Audio
Realtek® ALC897 Codec
 
 Supports S/PDIF output
Continued on next column

MSI MAG B560 TOMAHAWK WIFI Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel B560
Audio output channels	7.1 channels
Motherboard form factor	ATX
Memory channels	Dual-channel
Memory slots type	DIMM
Unbuffered memory	Yes
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2666, 2933, 3200, 4000, 4266, 4600 MHz
PCI Express x16 slots	2
Number of M.2 (M) slots	3
PCI Express x1 (Gen 3.x) slots	1
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	2-Way CrossFireX
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Number of SATA II connectors	0
Number of SATA III connectors	6
LAN controller	Realtek RTL8125B
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX210
Ethernet interface type	2.5 Gigabit Ethernet
BIOS type	UEFI AMI
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Harmonized System (HS) code	84733020
Weight	1000 g

Weight and Dimensions

Width	244 mm
Height	70 mm
