MSI MAG B650 TOMAHAWK WIFI - JAUD1: Front Audio Connector; JFP1, JFP2: Front Panel Connectors

34
6. Remove the protective film from the thermal pad under the M.2 Shield Frozr
heatsink.
7. Put the M.2 Shield Frozr heatsink back in place and secure it.
66
77
77

Important
PCI_E2 & M2_3 share the bandwidth. PCI_E2 will run at x2 speed and M2_3 will run at
x2 speed when installing devices in both slots.
