15
Specifications
CPU
∙ Supports 12th/ 13th Gen Intel® Core™ Processors,
Pentium® Gold and Celeron® Processors*
∙ Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® B760 Chipset
Memory
∙ 4x DDR5 memory slots, supporting up to 128GB*
∙ Supports 1R 5600 MHz (by JEDEC & POR)
∙ Max. overclocking frequency:
• 1DPC 1R Max speed up to 7000+ MHz
• 1DPC 2R Max speed up to 6600+ MHz
• 2DPC 1R Max speed up to 6400+ MHz
• 2DPC 2R Max speed up to 5600+ MHz
∙ Supports Intel® XMP 3.0 OC
∙ Supports Dual Controller Dual-Channel mode
∙ Supports non-ECC, un-buffered memory
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
∙ 2x PCIe x16 slots
• PCI_E1 slot (From CPU)
• Supports PCIe 5.0 x16
• PCI_E2 slot (From B760 Chipset)
• Supports PCIe 3.0 x4
∙ 1x PCIe x1 slot
• PCIE_E3 slot (From B760 Chipset)
• Supports PCIe 4.0 x1
Onboard Graphics
∙ 1x HDMI™ 2.1 port with HDR, supporting a maximum
resolution of 4K 60Hz*/ **
∙ 1x DisplayPort 1.4 port with HBR3, supporting a maximum
resolution of 8K 60Hz*/ **
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports
4x SATA 6Gb/s ports* (From B760 chipset)
* SATA7 will be unavailable when installing M2.SATA SSD in the M2_3 slot.
Continued on next column
