MSI MAG X570 TOMAHAWK WIFI User Manual

16
Specifications
Continued from previous page
Onboard Graphics
∙ 1x HDMI 1.4 port, supports a maximum resolution of
4096x2160 @24Hz*
* Only support when using Ryzen™ with Radeon™ Vega Graphics and 2nd Gen
AMD Ryzen™ with Radeon™ Graphics Processors
* Maximum shared memory of 2048 MB
Multi-GPU ∙ Supports 2-Way AMD
®
CrossFire
™
Technology
LAN ∙ 1x Realtek
®
8125B 2.5Gbps LAN Controller
Wireless LAN &
Bluetooth
®
Intel
®
Wi-Fi 6 AX200
▪ Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-
5GHz (160MHz) up to 2.4Gbps
▪ Supports Bluetooth
®
5
▪ The Wireless module is pre-install in the M2_WIFI1
(Key-E) slot
Storage
∙ 6x SATA 6Gb/s ports (from AMD
®
X570 Chipset)
∙ 2x M.2 slots (Key M)*
▪ M2_1 slot (from AMD
®
Processor)
▫ Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™)
▫ Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/
Ryzen™ with Radeon™ Vega Graphics and 2nd Gen
AMD Ryzen™ with Radeon™ Graphics)
▫ Supports 2242/ 2260/ 2280/ 22110 storage devices
▪ M2_2 slot (from AMD
®
X570 Chipset)
▫ Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™)
▫ Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/
Ryzen™ with Radeon™ Vega Graphics and 2nd Gen
AMD Ryzen™ with Radeon™ Graphics)
▫ Supports SATA 6Gb/s
▫ Supports 2242/ 2260/ 2280 storage devices
RAID ∙ Supports RAID 0, RAID 1 and RAID 10
Audio
Realtek
®
ALC1200 Codec
∙ 7.1-Channel High Definition Audio
∙ Supports Optical S/PDIF output
I/O Controller NUVOTON NCT6797 Controller Chip
Continued on next page

MSI MAG X570 TOMAHAWK WIFI Specifications

General

Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Supported processor sockets	Socket AM4
Audio chip	Realtek ALC1200
Cooling type	Active
Component for	PC
Motherboard chipset	AMD X570
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4533, 4600 MHz
PCI Express x16 (Gen 4.x) slots	2
Number of SATA II connectors	0
Number of SATA III connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
LAN controller	Realtek RTL8125B-CG
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
Ethernet interface type	2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
DirectX version	12.0
Maximum graphics card memory	2048 MB
Parallel processing technology support	CrossFire
BIOS type	UEFI AMI
ACPI version	6.1
BIOS memory size	256 Mbit
System Management BIOS (SMBIOS) version	2.8
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	305 mm
Width	244 mm
