MSI MEG Ai1300P PCIE5 User Manual

2
Specifications
1300W
AC Input
100-240V~, 15A Max, 50-60Hz
For use in China only: 200-240V~, 8A, 50-60Hz
DC Output
(Single-rail,
default)
+5V +3.3V +12V -12V +5Vsb
25A 25A 108.33A 0.3A 3A
DC Output
(Multi-rail*)
+5V +3.3V +12V1 +12V2 +12V3 +12V4 +12V5 -12V +5Vsb
25A 25A 40A 50A 50A 50A 50A 0.3A 3A
Total Power
130W 1300W 3.6W 15W
1300W
1000W
AC Input
100-240V~, 15A Max, 50-60Hz
For use in China only: 200-240V~, 8A, 50-60Hz
DC Output
(Single-rail,
default)
+5V +3.3V +12V -12V +5Vsb
22A 22A 83.33A 0.3A 3A
DC Output
(Multi-rail*)
+5V +3.3V +12V1 +12V2 +12V3 +12V4 +12V5 -12V +5Vsb
22A 22A 40A 50A 50A 50A 50A 0.3A 3A
Total Power
130W 1000W 3.6W 15W
1000W
* Please refer to “Software Control and Monitoring” section to download and install
MSI Center to activate 12V multi-rail output.

MSI MEG Ai1300P PCIE5 Specifications

General

Cabling type	Fully-Modular
Motherboard power connector	24-pin ATX
ATX Power connector (24-pin)	Yes
Motherboard power cable length	600 mm
Number of SATA power connectors	16
PCI Express power connectors (6-pin)	0
PCI Express power connectors (6+2 pin)	8
Peripheral (Molex) power connectors (4-pin)	4
Efficiency	92 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Combined power (+12V)	1300 W
Combined power (+3.3V)	130 W
Max output current (+5V)	25 A
Max output current (-12V)	0.3 A
Power protection features	Over current, Over power, Over voltage, Short circuit, Under voltage
Maximum input current (@110V)	10 A
Maximum input current (@220V)	5 A
Power Factor Correction (PFC) type	Active
Fan diameter	120 mm
Illumination	No
Product color	Black
Number of fans	1 fan(s)
Harmonized System (HS) code	84733020
Purpose	PC
Noise level	- dB
Country of origin	China
80 PLUS certification	80 PLUS Gold
Power supply unit (PSU) form factor	ATX

Weight and Dimensions

Depth	16 mm
Width	150 mm
Height	86 mm
Weight	- g
