Specifications
CPU
 Supports 13th and 12th Gen Intel® Core™ Processors,
Pentium® Gold and Celeron® Processors
 Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new
processors are released.
Chipset Intel® B760 Chipset
Memory
 2x DDR5 memory slots, support up to 96GB*
 Supports 1R 5600 MHz (by JEDEC & POR)
 Max overclocking frequency:
• 1DPC 1R Max speed up to 7200+ MHz
• 1DPC 2R Max speed up to 6600+ MHz
 Supports Intel® XMP3.0 OC
 Supports Dual-Controller Dual-Channel mode
 Supports non-ECC, un-buffered memory
* Please refer to www.msi.com for more information on compatible memory
Expansion Slot
 1x PCIe x16 slot (From CPU)
• Supports up to PCIe 5.0 x16
Onboard Graphics
 1x HDMI™ 2.1 port with HDR, supports a maximum
resolution of 4K 60Hz*/ **
 1x DisplayPort 1.4 port with HBR3, supports a maximum
resolution of 8K 60Hz*/ **
*Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports  4x SATA 6Gb/s ports (From B760 chipset)
M.2 SSD Slots
 2x M.2 slots (Key M)
• M2_1 slot (from CPU)
• Supports PCIe 4.0 x4
• Supports 2280 storage devices
• M2_2 slot (from B760 chipset)
• Support PCIe 4.0 x4
• Support SATA 6Gb/s*
• Support 2280 storage devices
* The SATA8 port will be unavailable when installing M.2 SATA SSD into M2_2.
Continued on next column

MSI MPG B760I EDGE WIFI Specifications

General

Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium Gold
Supported processor sockets	LGA 1700
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR5-SDRAM
Maximum internal memory	96 GB
Supported memory clock speeds	7200, 7000, 6800, 6600, 6400, 6200, 6000, 5800, 5600, 5400, 5200, 5000, 4800 MHz
Supported memory clock speed (max)	7200 MHz
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth version	5.3
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Number of SATA III connectors	4
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	M.2, SATA III
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
System Management BIOS (SMBIOS) version	3.5
Parallel processing technology support	-
Audio chip	Realtek ALC897
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B760
Audio output channels	7.1 channels
Motherboard form factor	mini ATX
Windows operating systems supported	Windows 10, Windows 11

Weight and Dimensions

Width	170 mm
