MSI MPG X570S CARBON MAX WIFI User Manual

9
Specifications
Continued from previous page
Internal Connectors
 1x 24-pin ATX main power connector
 1x 8-pin ATX 12V power connector
 1x 4-pin ATX 12V power connector
 8x SATA 6Gb/s connectors
 2x USB 2.0 connectors (supports additional 4 USB 2.0
ports)
 2x USB 3.2 Gen 1 5Gbps connectors (supports additional 4
USB 3.2 Gen 1 5Gbps ports)
 1x USB 3.2 Gen 2 10Gbps Type-C port
 1x 4-pin CPU fan connector
 1x 4-pin water-pump connector
 6x 4-pin system fan connectors
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis Intrusion connector
 1x 2-pin Thermal sensor connector
 1x TPM module connector
 1x Tuning Controller connector
Jumpers  1x Clear CMOS jumper
LED Features
 1x 4-pin RGB LED connector
 2x 3-pin RAINBOW LED connectors
 1x 3-pin CORSAIR LED connector
 4x EZ Debug LED
 1x 2-Digit Debug Code LED
 1x EZ LED Control switch
BIOS Features
 1x 256 Mb flash
 UEFI AMI BIOS
 ACPI 6.0, SM BIOS 2.8
 Multi-language
Form Factor  ATX Form Factor
 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Continued on next page

MSI MPG X570S CARBON MAX WIFI Specifications

General

Ethernet LAN	Yes
LAN controller	Realtek RTL8125B
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX210
Ethernet interface type	2.5 Gigabit Ethernet
DVI-D ports quantity	0
USB 2.0 ports quantity	2
Digital audio optical out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Cables included	SATA
Number of SATA III connectors	8
BIOS type	UEFI AMI
Parallel processing technology support	Crossfire
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3600, 4000, 4266, 4400, 5100, 5300 MHz
Audio chip	Realtek ALC4080
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	ATX
Number of mounting holes	9
Motherboard chipset family	AMD
Windows operating systems supported	Windows 10 x64
Processor socket	Socket AM4
Compatible processor series	AMD Ryzen 3, AMD Ryzen 5, AMD Ryzen 7, AMD Ryzen 9 3rd Gen, AMD Ryzen 9 5th Gen
Harmonized System (HS) code	84733020
Weight	1000 g

Weight and Dimensions

Depth	244 mm
Width	305 mm
Height	268 mm
